Street sweeper truck (also called road sweeping truck, road sweeper, street sweeper, street cleaning truck, municipal vehicle, sweeping vehicle) is kind of vacuumed type truck mounted road sweeping machine, it is specially used in road cleaning and collecting rubbish and transporting them to garbage collection spot.
The road sweeper truck is composed by chassis, auxiliary engine, air blower, magnetic valve, sweeping system, suction system, water sprinkling system, hydralic system, etc.
Features:
1. FOTON Chassis and FOTON engine, powerful, reliable performance, no overhaul with 100,000 km.
2. Large cleaning width, low oil consumption, easy operation.
3. Dustbin and water tank are made of stainless steel.
4. The Street Road Sweeper truck is designed and developed on the basis of the FOTON light truck special vehicle chassis to meet needs of sweeping and cleaning urban pavement and curb. The principle of pure suction under negative pressure is adopted to guarantee strong suction force, dust-free working, simple operation, and excellent performance. It can quickly and efficiently sweep the household garbage and spilled objects in streets and roads.
Technical Specification:
DONGFENG Water Tank Street Sweeper Truck
Vehicle details
Vehicle
brand
CSC
GVW
7500 kg
Kerb
Weight
4025 kg
Overall
dimension
6000x2200x2650 mm
Cab
Cab capacity
3 persons'
seat with air condition
Chassis
Chassis brand
DONGFENG
Drive Type
4X2, Left
hand drive
Fuel Type
Diesel
Engine
Make
Yuchai Engine
Horse
power
120 HP (88kw)
Displacement
3800 cc
Air
conditioner
Equipped
Type of
fuel
Diesel
Emission
standard
Euro III
Transmission
6-speed
forward, 1-reverse
Brake
Air Brake
No. of
axles
2
Tyre
7.00R16/(6+1)pcs
Superstructure
details
Water Tank
Capacity
1,500
Liters Carbon steel
Dustbin tank
capacity
4 cbm,
Stainless steel
Max.
suction particle
120 mm
Min. clearance
of suction nozzle
200 mm
Cleaning
capacity
9000-60000(m2/h)
Max. Unloading
angle
45 degree
Sweep width
3200 mm
Sweeper
brush
4 pcs
Auxiliary
engine
JMC engine,
(ISUZU technology),77HP (57KW)
