FAW 8X4 21 m3 Heavy Duty Tipper Truck

Dump truck

FAW 8X4 21 m3 Heavy Duty Tipper Truck

Dump truck is a vehicle that unloads goods by hydraulic or mechanical lifting. Also known as a dumper. It consists of automobile chassis, hydraulic lift mechanism, cargo box and retraction device.

The car of the dump truck is divided into two types: backward overturning and lateral overturning. The movement of piston rod is controlled by the control system. The backward tilting is more common, and the piston rod is pushed to make the car overturn and a few of them are bidirectional overturned.

  • product details

Truck description:

CNCSC dump truck (include dump tipper truck,tipper lorry,dumper,tipper truck,  dump tipper,tip truck,dumper) is suitable for mining and rock excavation and construction site to transport sand ,stone,bulk material,coal,wood,and etc.


Advantage:

  1. High quality carbon steel plate,durable and strong cargo box.

  2. Different cargo box shape, “U” type,Grid shape,or as request.

  3. Box dioxide protected welding ensure good appearance and reliable quality.

  4. China famous brand cylinder.

  5. Emission standard: Eruo II, Eruo III, Eruo IV,Eruo V

  6. Drive type:Left hand drive (LHR),Right hand drive (RHD)


Technical Specification:

We are able to custom manufacture Dump truck in a wide range of sizes and capacities as per customers' requirement.

 Tipper Truck FAW 21 m3

Truck Description

Type

8X4 dump truck

GVW (kg)

31000

Kerb weight (kg)

11000

Overall

dimension (mm)

Length

8950,8750

Width

2550

Height

3400

Box dimension (mm)

Length

6000

Width

2350

Height

1500

Chassis

Chassis brand

FAW

Number of axles

4

Type of fuel

Diesel

Engine brand

FAW

Tire specification

10.00R20,12R22.5 for option

Tire quantity

12+1 (with spare tyre)

Cargo box

Material

Q235 carbon steel

Thickness

Side (mm)

8 or changed as request

Bottom(mm)

10 or changed as request

Other remark

Above specification is just for reference,please send us your request details.

Contact us





CNCSC truck is China leading professional truck manufacturer,  we offer you various heavy duty truck, trailer and truck parts. contact us and get a detail of our trucks.
