Howo 12,000L waste compactor vehicle

Garbage Compactor Truck

Howo 12,000L waste compactor vehicle

The waste disposal truck has a high compression ratio and a large loading capacity. Its maximum crushing pressure can reach 12 tons, and its loading capacity is equivalent to two and a half times that of non-compressed garbage of the same tonnage. This design enables the garbage truck to collect more garbage in the same trip, reducing the number of round trips and improving work efficiency.

  • product details

Truck description:

The computer control system of the refuse disposal truck can automatically control the throttle, improve fuel efficiency, and reduce operating costs. At the same time, the vehicle is equipped with multiple mechanism options, such as a rear dump mechanism or a garbage dump mechanism, which are suitable for different operational needs.

Advantages:

1.The fully sealed design of the garbage compressor can prevent secondary pollution.

2.The garbage collection vehicle is fully automated, requiring only one driver to operate, greatly reducing the labor intensity of sanitation workers.

3.The compressed garbage truck is safer to use and more durable.

Truck description

GVW (kg)

16000

Kerb weight (kg)

7850

Overall

dimension (mm)

Length

8500

Width

2550

Height

3450

Chassis

Number of axles

2

Allowable Passengers in cab

3

Air conditioner

For option

Wheel base(mm)

4600

Type of fuel

Diesel

Exhaust/output

9726ml/213kw

Tire specification

12.00Rfor option

Tank description

Material

Q345 manganese steel

Thickness

Side plate (mm)

3 or changed as request

Bottom plate(mm)

4 or changed as request

compression

 parameter

garbage density after compression

0.5-0.8t/m3

full filling one time

less than 30S

one time unloading

less than 40S

compression ratio

more than 1:2.5

Other remark

Above specification is just for reference, please send us your request details.
