The waste disposal truck has a high compression ratio and a large loading capacity. Its maximum crushing pressure can reach 12 tons, and its loading capacity is equivalent to two and a half times that of non-compressed garbage of the same tonnage. This design enables the garbage truck to collect more garbage in the same trip, reducing the number of round trips and improving work efficiency.
Truck description:
The computer control system of the refuse disposal truck can automatically control the throttle, improve fuel efficiency, and reduce operating costs. At the same time, the vehicle is equipped with multiple mechanism options, such as a rear dump mechanism or a garbage dump mechanism, which are suitable for different operational needs.
Advantages:
1.The fully sealed design of the garbage compressor can prevent secondary pollution.
2.The garbage collection vehicle is fully automated, requiring only one driver to operate, greatly reducing the labor intensity of sanitation workers.
3.The compressed garbage truck is safer to use and more durable.
Truck description |
GVW (kg) |
16000 |
|
Kerb weight (kg) |
7850 |
||
Overall dimension (mm) |
Length |
8500 |
|
Width |
2550 |
||
Height |
3450 |
||
Chassis |
Number of axles |
2 |
|
Allowable Passengers in cab |
3 |
||
Air conditioner |
For option |
||
Wheel base(mm) |
4600 |
||
Type of fuel |
Diesel |
||
Exhaust/output |
9726ml/213kw |
||
Tire specification |
12.00Rfor option |
||
Tank description |
Material |
Q345 manganese steel |
|
Thickness |
Side plate (mm) |
3 or changed as request |
|
Bottom plate(mm) |
4 or changed as request |
||
compression parameter |
garbage density after compression |
0.5-0.8t/m3 |
|
full filling one time |
less than 30S |
||
one time unloading |
less than 40S |
||
compression ratio |
more than 1:2.5 |
||
Other remark |
Above specification is just for reference, please send us your request details. |
||
