Truck Description:
CSC fire fighting truck (also known as fire truck,
water fire truck, foam fire truck, powder fire truck, fire extinguishing truck,
fire engine, fire fighting equipment, fire apparatus, fire rescue truck, fire equipment
truck) is widely used in rural/urban fire brigades, petrochemical field,
industrial factory & mining enterprises, forest, ports, docks etc. Fire trucks
are used to transport firemen and fire equipment to fire scene to carry out
fire extinguishing work.
Advantage:
1. Tank material: carbon steel or stainless steel.
2. Top brand XZ/RS fire pump and PS/PF/PL fire cannon.
3. Body top is made of M.S checkered steel plate for
anti-slip purpose.
4. Cabin top long row warning lights; one light at the
rear of the vehicle.
5. Aluminum alloy rolling doors/shutters are installed
on three sides for easy access to fire equipment.
6. Drive type: 4x2, 6x4, 8x4, 4x4, 6x6; Left hand
drive, right hand drive.
Technical Specification:
RHD SINOTRUK HOWO 5000 Liters Foam Tanker Fire Fight Truck
|
Vehicle
Parameters
|
General
|
Vehicle Brand
|
Chusheng
|
Chassis Brand
|
SINOTRUK - HOWO
|
Overall Dimension (mm)
|
7150x2200x3160 mm
|
Gross Vehicle Weight (kg)
|
11,000 kg
|
Curb/Net Weight (kg)
|
Approx.: 5500 kg
|
Chassis
Parameters
|
Cab
|
Seat Capacity
|
3+3 seats
|
A/C
|
Yes
|
Engine
|
Fuel Type
|
Diesel
|
Engine Brand
|
Yunnei Turbo Engine
|
Power (HP/KW)
|
116 HP
|
85 KW
|
Displacement (ml)
|
3760 ml
|
Emission Standard
|
Euro 3
|
Chassis
|
Drive Type
|
4x2, Left hand drive
|
Gear Box
|
WLY brand manual gear box, 6 forward speed & 1 reverse.
|
Wheelbase (mm)
|
3800 mm
|
Tire Specification
|
7.50R16
|
Tire No. (pcs)
|
6+1 pcs
|
Max Speed (km/h)
|
95 km/h
|
Fire Fighting Structure
Parameters
|
Water Tank Material/Capacity
|
Carbon steel
|
4,000 Liters
|
Foam Tank Material/Capacity
|
Stainless steel
|
1,000 Liters
|
Fire Pump Pressure/Flow
|
1.0 MPa
|
30 L/S
|
Fire Cannon
|
Water Pressure/Flow
|
1.0 MPa
|
24 L/S
|
Foam Pressure/Flow
|
1.0 MPa
|
24 L/S
|
Fire Cannon Shot
|
Water Shot
|
≥ 50 Meter
|
Foam Shot
|
≥ 50 Meter
|
Suction Head
|
7 Meter
|
Fire Accessories
|
Suction hose, water strainer, water segregator, water collector, fire
hose, hose patch, hose bridge, hydrant wrench, fire gun, portable fire
extinguisher, fire axe etc.
|
