Introduction:
Dongfeng Kingrun Garbage Collection Truck items to maximize the number of loads that can be transported at one time.In 2001, our company started building refuse container bodies to be assembled on imported compactor heads. The following year, we started making our own refuse compactors.
Product Futures:
1. Garbage capacity: 4 CBM to 20 CBM (3 Tons to 15 Tons).
2. High-strength anti-corrosion plate, long service life.4. Dual control system: manual and electrical.
5. High compression ratio.
Technical Specification:
Dongfeng Kingrun Garbage Collection Truck ( 10-14 m³) |
||
General |
Vehicle Brand |
CSC |
Chassis Brand |
Dongfeng Kingrun |
|
Overall Dimension |
8850x2500x3200 mm |
|
GVW / Kerb Weight |
18,000kg / 10,200 kg |
|
Cab |
Cab Capacity |
3 persons allowed |
Air Conditioner |
W/ air conditioner |
|
Engine |
Fuel Type |
Diesel |
Engine Brand |
Cummins engine |
|
Power |
190 Hp (140 KW) |
|
Displacement |
5900 ml |
|
Emission Standard |
Euro 3 |
|
Chassis |
Drive Type |
4X2, left or right hand drive |
Transmission |
8-speed front, 1 reverse |
|
Wheelbase/No. of axle |
4500 mm / 2 |
|
Tyre Specification |
10.00R20 |
|
Tyre Number |
6 tyres and 1 spare tyre |
|
Max Speed |
90 km/h |
|
Paint |
Metallic paint |
|
Superstructure |
Waste Box Capacity |
10-14 M3 |
Waste Box Material |
Carbon steel |
|
All other standard accessories: Tool kit, English manual and so on. |
