SHACMAN 4 Axle Hydraulic Dump Truck 60T
Heave Duty Tipper truck is used for transporting sand, gravel, coal, dirt and loose material etc.It has the characteristics of convenient installation and maintenance, large tonnage and long service life.
Technical Specification:
ISUZU 7CBM Dump Tipper Truck
Vehicle Parameters
General
Vehicle Brand
Chusheng
Chassis Brand
ISUZU
Overall Dimension (mm)
Approx.: 6650x2200x2520 mm
Gross Vehicle Weight (kg)
10,550 kg
Curb/Net Weight (kg)
Approx.: 5,300 kg
Chassis Parameters
Cab
Seat Capacity
3 seats
A/C
Yes
Engine
Fuel Type
Diesel
Engine Brand
ISUZU Turbo Engine
Power (HP/KW)
190 HP
139 KW
Displacement (ml)
5193 ml
Emission Standard
Euro 6
Chassis
Drive Type
4x2, Left/Right hand drive
Gear Box
ISUZU MLD manual gear box, 6 forward speed
& 1 reverse.
Wheelbase (mm)
3815 mm
Tire Specification
235/75R17.5, 8.25R20
Tire No. (pcs)
6+1 pcs
Max Speed (km/h)
95 km/h
Top Structure Parameters
Box Dimension
Approx.: 4300x2100x800 mm
Box Material
Carbon steel
Box Thickness
Side plate 3mm; floor plate 4mm
