1.ISUZU FVZ BRAND CHASSIS With air condition,
2.power steering.
3.Color: White body and white cabin
4.Drive type: LHD or RHD
5. Engine : ISUZU 6HK1-TCH 300HP
6. 11.00R20 tyres
7.Dump Cargo size:5400*2300*110mm
8. Loading capacity:15Tons 18Tons
9. ISUZU FVZ Dump Truck , factory directly sales
10.more than 15 years of experience in exporting specialized vehicles
Item No :
300HP ISUZU FVZ Dump Truck 15T -18T Tipper VehicleOrder(MOQ) :
1Payment :
T/T LC At SightProduct Origin :
Suizhou City, Hubei Province ChinaColor :
Customized ColorShipping Port :
Shanghai, Tianjin ,Qingdao Horogos, Erlianhot Etc China Main export PortLead Time :
35-45 days
300HP ISUZU FVZ Dump Truck 15T -18T Tipper Vehicle :
| Products Technical Specification | |
| Type | Dumper Truck |
| Brand | ISUZU 6*4 |
| Cab | With A/C, on bed |
| Vehicle Description | |
| Overall dimensions（mm） | 8600*2500*3500 |
| Curb weight(vehicle) (kg) | 9800 |
| Max speed (Km/h) | 110 |
| Engine | |
| Mode | 6HK1-TCH |
| Type | Diesel, 6-cylinder in line with water cooling,turbo-charging |
| Max. power/rotated speed | 177(KW) / 300HP |
| Displacement(ML) | 7790 |
| Company of engine | ISUZU Motor |
| Emission level | Euro 5 |
| Chassis Description | |
| Wheel base | 4000+1300 |
| Front axle | Elliot I-beam type 7T |
| Rear axle | Driving axle, 18T*2 |
| Gear box | Fast 9 forwards |
| Brake system | Air braking |
| Operation control system | Power Steering |
| Electric system | 24V |
| Tyres | 11.00R20 |
| Dumper | |
| Cargo size | 5600*2300*1200mm |
| Bottom thickness : 8mm | |
| Side body thickness:6mm | |
| 180# Front cylinder | |
| FAST 9 forwards + 1 reverse, with air condition, power steering, Electrical glass, ABS | |
| Chassis Steel: Q345R (16MnR) | |
| Cabin Steel: Cold-Rolled Carbon Steel Q235 | |
| System Brake: air Brake | |
| Front Axle( Loading capacity): 7T | |
| Rear Axle( Loading Capacity): 18T *2 | |
| Battery: 12V*2 115Ah*2 | |
