Rubbish Compactor Truck consists of sealed garbage compartment, hydraulic system and operating system. The whole truck is fully sealed, self-compressed, self-dumped, and all the sewage in the process of compression is entered in the sewage compartment, which completely solves the problem of secondary pollution in the process of garbage transportation and avoids inconvenience to people.
Truck Description:
CSC Rubbish Compactor Truck(also called as bin lorry, compressed garbage truck, dirt-wagon, dust cart trash truck, refuse collection truck, dustcart, waste collection vehicle) is designed for daily rubbish transport in such living areas as all kinds of cities, large station, port and wharf, airport, and densely-populated areas like industrial and mineral enterprises and military units.
Advantage:
1. JAC brand chassis, perfect performance, JAC engine, super powerful, reliable performance.
2. High pressure, good sealing, convenient operation and safety.
3. High compression ratio and large loading capacity.
4. Computer control system to reduce the labor intensity of sanitation workers, and greatly improve the working environment.
5. Compression body capacity from 4 to 18 CBM
Technical Specification:
Trash Collection Truck JAC ( 5 m³ ) |
||
General |
Vehicle Brand |
CSC |
Chassis Brand |
JAC |
|
Overall Dimension |
6480x2050x2550 mm |
|
GVW / Kerb Weight |
7,340kg / 5,100 kg |
|
Cab |
Cab Capacity |
2 persons allowed |
Air Conditioner |
Equipped air conditioner |
|
Engine |
Fuel Type |
Diesel |
Engine Brand |
Yunnei |
|
Power |
116 HP (85KW) |
|
Displacement |
3760 ml |
|
Emission Standard |
Euro III, Euro IV |
|
Chassis |
Drive Type |
4X2, left or right hand drive |
Transmission |
6 forward gears and 1 reverse |
|
Wheelbase/No. of axle |
3360 mm / 2 |
|
Tyre Specification |
7.00R16 |
|
Tyre Number |
6 tyres and 1 spare tyre |
|
Max Speed |
90 km/h |
|
Paint |
Metallic paint |
|
Superstructure |
Garbage Compactor Capacity |
5 CBM |
Garbage Compactor Material |
Anti – corrosive material |
|
Control Method |
Both manual and electrical control |
|
All other standard accessories: Tool kit, English manual…… |
||
Optional |
Bin lifter device, half-seal hopper lifter device, complete-seal hopper lifter device… |
