Truck Description:
CSC garbage compactor truck (also known as garbage truck, compressed garbage truck, refuse collection truck, waste collection vehicle, dirt-wagon, dust cart trash truck, dustcart, and bin lorry) is a special purpose vehicle used to collect and transport all kinds of garbage in municipal sanitation department.
Advantage:
1. The garbage box is made of high strength wear resistant steel plate, prolonging box service life.
2. Top China brand cylinders and multi-way valve, high hydraulic pressure and high compression ratio up to 2.5:1, ensuring better loading capacity.
3. Intelligent integrated control panel, easier to operate and greater efficiency; the multi-way valve control always available just in case.
4. Two sewage tanks system: one sewage tank under loading container, the other sewage tank under garbage box. All sewage goes into the tanks to avoid dripping during compacting and transportation.
5. Compression box capacity from 3-20 CBM.
6. Various types of garbage bin lifting device available.
Technical Specification:
Garbage compactor truck rear lift device can be
customized to suit different type garbage bin.
SAGMOTO 20 CBM Waste Compacting and Transport Truck
Vehicle
Parameters
General
Vehicle Brand
Chusheng
Chassis Brand
SHACMAN - H3000
Overall Dimension (mm)
Approx.: 11200x2550x3450 mm
GVW (kg)
25000 kg
Curb/Net Weight (kg)
15500 kg
Chassis
Parameters
Cab
Seat Capacity
2 seats and sleeper
A/C
Yes
Engine
Fuel Type
Diesel
Engine Brand
Cummins Turbo Engine
Power (HP/KW)
345 HP
254 KW
Displacement (ml)
10800 ml
Emission Standard
Euro 2
Chassis
Drive Type
6x4, Left hand drive
Gear Box
FAST brand manual gear box, 10 forward speed & 2 reverse.
Wheelbase (mm)
4375+1400 mm
Tire Specification
12.00R20
Tire No. (pcs)
10+1 pcs
Max Speed (km/h)
95 km/h
Garbage
Compactor Structure Parameters
Box Capacity
20 CBM
Box Material
High strength wear resistant steel plate
Multi-way Valve
Top China brand or Italy imported brand
Hydraulic Cylinder
Top China brand
Lifting Device
Multiple garbage bin lifting devices optional to
suit different type garbage bin, please see as below demonstration
Sewage Tank
Two tanks. Equipped to avoid secondary pollution
Optional
Imported multi-way valve; Siemens PLC; HZL hydraulic
cylinder; Rear cover; Dustpan loading container
